I don't have a picture, but I have a 460/c6 in my 67. I used the same linkage that was on my old FE/c6 setup. I don't remember for sure, but I think I had to use the bell crank that was on the 429/460. I used a Lockar setup for the kickdown. IF the Tbird had a floor shift then the shift tab on the transmission is 180 degrees off. Currently working on the Holley Truck Avenger carb on my 460 in the 84 Bronco after replacing the blown-up 351W. Looking for a diagram or good pic of how the C6 tranny kickdown rod linkage hooks up to the carb, as well as down at the other end. The C6 came out of the same 88 F-350 as the 460...

Oct 15, · Looking for a diagram or good pic of how the C6 tranny kickdown rod linkage hooks up to the carb, as well as down at the other end. The C6 came out of the same 88 F as the motor, so it had a kickdown cable. Apr 01, · C6 kickdown linkage When I bought the yellow truck (79 F C6) it had a Holley, a 3/4" spacer and an Offy manifold.

C6 kickdown linkage diagram

The accelerator linkage has two arms, one going up to that connects to the carb,and the kick down cable arm which faces downwards, close to the bell housing. That is the arm that this kick down cable attaches to (which is why I couldn't see it in any of my hundreds of pictures). The other end of this cable connects to the tranny. Step 2: Install the kickdown lever onto the transmission, with the cable hole towards the transmission as shown in Fig. 4 for C4 and Fig. 5 for C6. Step 3: Install the trans cable bracket and the cable housing onto the transmission as shown in Fig. 4 for C4 and Fig. 5 for C6. NOTE:These photos show the inner wire, It runs a spool in the valve body that raises a "counter pressure" on the shift spools, resulting in later shift points - and a "kick down" when in third. There's no adjustment. for it on the trans, it's done with the linkage. All the C6 oil diagrams are here about 2/3 the way down the page, left columb. I think.

C6 kickdown linkage diagram. 1956-1957 Corvette Auto Transmission Kickdown Linkage. 56-57 Auto Transmission Kickdown Linkage. Be the first to review this product. Item #: CZ-1030. $229.99. Out Of Stock - This item is not available to ship but can be ordered. Most out of stock items are available to ship within 7-10 days. Qty - +. Do you really need your kick down linkage on a ford c4 and c6. Do you really need your kick down linkage on a ford c4 and c6. The automatic transmission (C6) in my 66 Fairlane GT/A (390 engine) was recently overhauled internally. When tested on the road it works fine and shifts up smoothly, however, there is a BIG "but": it won't downshift when conditions require it (a hill, or in general applying a heavier load on the car) and it will not "kick-down" either. C6 Kickdown Rods Kickdown Rods for C6. There were two C6 kickdown rods - one for the CJ with the Rochestor carburetor, D1ZZ-7A187-H (above left) and one for the SCJ with the Holley carburetor, D1ZZ-7A187-K (above right). The two rods are similar in that they each have a bend to avoid the carb secondary linkage.

These kick down devices created a physical link between the accelerator and the shift linkage. In 1968, a mechanism with multiple rods and a cable was used. In 1969 and 1970, a rod and linkage mechanism was used. Id venture to say any C6 with a slip in modulator. Again, PURPLE and GREEN are NOT the correct units to use, BLACK is the intended modulator as was designed for TRUCKS; by MyFullSize (Andrew) ... Shift Linkage Parts Break-Out Diagram in an 88 with ... (Dustball, Mellow Yellow, Mr. Laser Boy) Kick Down; "...I believe it's 1987+ that uses a cable ... C6 Kickdown Linkage Diagram Ford C6 Dual-Action Shifter Installation Video from American Shifter Co. C6 kickdown linkage - Hey Y'all! if you go to Lokar's site and do a search, they have the directions for installation online along with diagrams. I don't have a diagram that is easy to post, however it is important to remember that the carb needs the appropriate pieces too. The linkage is a simple piece of tubing that is bent to clear the engine/trans and attach to the kickdown lever. It has a hole on either end. The adjustment is straight forward and done at the aforementioned carb piece.

1965-1968 Mustang Kickdown Rod Conversion Kit-All FE Engines-2 or 4 Barrel Carb. from 139.00. 1966-1971 Ford Full Size Cars, 390 C6 2V Transmission Kickdown Rod. from 88.00. 1966-1971 Ford Full Size Cars, 390 C6 2V Transmission Kickdown Rod. from 88.00. The first step to installing your new Mustang Scott Drake C6OZ-7A187-KIT Transmission Kick Down Cable Kit is to raise the front of the car off the ground. Ramps or jack stands work. 2. Open your Scott Drake kit and make sure all parts are there. There should be one arm with a C-clip attached, one regular and one lock washer, one nut, one spring ... Kickdown linkage illustrations and part numbers as used in the 1980 - 1986 Ford trucks. The "kickdown linkage" comes in three varieties: 7F042: A cable for the AOT as Ford called it, or AOD as it is known; 7A187: A rod (cable?) for the C4, C5, and C6 transmissions; 7F332: A rod for the AOT/AOD Step 4: Remove the kickdown cable from the mounting bracket. How to adjust the C6 kickdown linkage diagram? Step 3: Install the trans cable bracket and . linkage is adjusted correctly, slide the kickdown throttle body fitting. The PO of my 79 never installed the C6 kickdown when he did the swap.
